self.NLP(3-1). Pytorch 기본설명.

 What is different between Pytorch and Tensorflow?

Pytorch	Tensorflow(keras)	생성 / 구현
nn.Linear	keras.layers.Dense	Dense 층
nn.Module	keras.layers.Layer	모델구성 기반클래스
nn.Dropout	keras.layers.Dropout	Dropout 층
nn.LayerNorm	keras.layers.LayerNormalization	Layer Normalization
nn.Embedding	keras.layers.Embedding	Embedding 층
nn.GELU	keras.activations.gelu	GELU 활성화 함수
nn.Bmm	tf.matmul	Batch 행렬곱셈
model.forward	model.call	모델 정방향 패스





모델 정의 방법

tensorflow.keras

tf.debugging.set_log_device_placement(True)

class MyModel(tf.keras.Model):
    def __init__(self):
        super(MyModel,self).__init__()

        self.flatten = tf.keras.layers.Flatten(input_shape=(28,28))
        self.fc1 = tf.keras.layers.Dense(512,activation='relu')
        self.dropout = tf.keras.layers.Dropout(0.2)
        self.fc2 = tf.keras.layers.Dense(10, activation='softmax')

    def call(self,inputs):
        x = self.flatten(inputs)
        x = self.fc1(x)
        x = self.dropout(x)
        x = self.fc2(x)
        return x

model = MyModel()

cf) tensorflow는 tf.debugging.set_log_device_placement(True) 코드를 통해서 어디에 할당되어있는지를 확인할 수 있다.

PyTorch

# Get cpu or gpu device for training.
device = "cuda" if torch.cuda.is_available() else "cpu"

# Define model
class NeuralNetwork(nn.Module):
    def __init__(self):
        super(NeuralNetwork, self).__init__()

        self.flatten = nn.Flatten()
        self.linear_relu_stack = nn.Sequential(
            nn.Linear(28*28, 512),
            nn.ReLU(),
            nn.Linear(512, 512),
            nn.ReLU(),
            nn.Linear(512, 10)
        )

    def forward(self, inputs):
        x = self.flatten(inputs)
        logits = self.linear_relu_stack(x)
        return logits

model = NeuralNetwork().to(device)

모델 정의 시 차이점을 비교해 보자.

	GPU 할당	상속 클래스	fully connected layer	순방향 계산 함수명	모델 인스턴스 할당
PyTorch	cuda.is_available()	nn.Module	nn.Linear	call()	model.to(device)
Tensorflow	자동	keras.Model	keras.layers.Dense	forward()	model()

PyTorch는 GPU 탑재 여부를 담은 변수 device를 모델 객체에 할당할 때 포함시킵니다.
model = NeuralNetwork().to(device)

---

모델 컴파일 방법

tensorflow.keras

• tensorflow는 정의한 모델 객체의 complile 메서드를 통해서 optimizer , loss function , metrics를 정의.

model.compile(optimizer='adam',
              loss='sparse_categorical_crossentropy',
              metrics=['accuracy'])

PyTorch

• PyTorch는 optimizer , loss function 변수에 저장
• 저장된 변수를 학습 함수에서 직접 사용.

loss_fn = nn.CrossEntropyLoss()
optimizer = torch.optim.SGD(model.parameters(), lr=1e-3)

---

모델 학습 방법

차이점은 모델 학습 부분에서 가장 큰 차이를 보인다.

tensorflow.keras

• tensorflow 는 fit() 함수로 간단하게 학습을 사용할 수 있다.

model.fit(train_images, train_labels, epochs=5)

PyTorch

• PyTorch는 함수 속 for 문을 정의하여 모델 학습(train)과 검증(test) 코드를 구현해야 합니다.
  PyTorch가 구현하기 어렵지만 더욱더 직관적이고 학습하기 용이하다.

• optimizer.zero_grad() : Gradient를 초기화합니다.
  loss.backward() : Loss를 기준으로 Gradient를 저장합니다.
  optimizer.step() : 파라미터(weight) 업데이트.

def train(dataloader, model, loss_fn, optimizer):
    size = len(dataloader.dataset)
    model.train()
    for batch, (X, y) in enumerate(dataloader):
        X, y = X.to(device), y.to(device)

        # Compute prediction error
        pred = model(X)
        loss = loss_fn(pred, y)

        # Backpropagation
        optimizer.zero_grad()
        loss.backward()
        optimizer.step()

        if batch % 100 == 0:
            loss, current = loss.item(), batch * len(X)
            print(f"loss: {loss:>7f}  [{current:>5d}/{size:>5d}]")

def test(dataloader, model, loss_fn):
    size = len(dataloader.dataset)
    num_batches = len(dataloader)
    model.eval()
    test_loss, correct = 0, 0
    with torch.no_grad():
        for X, y in dataloader:
            X, y = X.to(device), y.to(device)
            pred = model(X)
            test_loss += loss_fn(pred, y).item()
            correct += (pred.argmax(1) == y).type(torch.float).sum().item()
    test_loss /= num_batches
    correct /= size
    print(f"Test Error: \n Accuracy: {(100*correct):>0.1f}%, Avg loss: {test_loss:>8f} \n")

epochs = 5
for t in range(epochs):
    print(f"Epoch {t+1}\n-------------------------------")
    train(train_dataloader, model, loss_fn, optimizer)
    test(test_dataloader, model, loss_fn)
print("Done!")





Ex) CIFAR100 with Pytorch

import torch
import torch.nn as nn
import torch.optim as optim
import torchvision
import torchvision.transforms as transforms

# Device 설정
device = torch.device("cuda" if torch.cuda.is_available() else "cpu")

# CIFAR-100 데이터셋 불러오기
transform = transforms.Compose([
    transforms.ToTensor(),
    transforms.Normalize((0.5, 0.5, 0.5), (0.5, 0.5, 0.5))
])

trainset = torchvision.datasets.CIFAR100(root='./data', train=True, download=True, transform=transform)
trainloader = torch.utils.data.DataLoader(trainset, batch_size=128, shuffle=True, num_workers=2)

testset = torchvision.datasets.CIFAR100(root='./data', train=False, download=True, transform=transform)
testloader = torch.utils.data.DataLoader(testset, batch_size=100, shuffle=False, num_workers=2)

# 신경망 모델 정의
class CNN(nn.Module):
    def __init__(self):
        super(CNN, self).__init__()
        self.conv1 = nn.Conv2d(3, 32, 3, padding=1)
        self.relu1 = nn.ReLU()
        self.pool = nn.MaxPool2d(2, 2)
        self.conv2 = nn.Conv2d(32, 64, 3, padding=1)
        self.relu2 = nn.ReLU()
        self.fc1 = nn.Linear(64 * 8 * 8, 512)
        self.relu3 = nn.ReLU()
        self.fc2 = nn.Linear(512, 100)

    def forward(self, x):
        x = self.pool(self.relu1(self.conv1(x)))
        x = self.pool(self.relu2(self.conv2(x)))
        x = x.view(-1, 64 * 8 * 8)
        x = self.relu3(self.fc1(x))
        x = self.fc2(x)
        return x

model = CNN().to(device)

# 손실 함수 및 최적화 알고리즘 정의
criterion = nn.CrossEntropyLoss()
optimizer = optim.SGD(model.parameters(), lr=0.001, momentum=0.9)

# 모델 학습
num_epochs = 100

for epoch in range(num_epochs):
    running_loss = 0.0
    for i, data in enumerate(trainloader, 0):
        inputs, labels = data[0].to(device), data[1].to(device)
        optimizer.zero_grad()

        outputs = model(inputs)
        loss = criterion(outputs, labels)
        loss.backward()
        optimizer.step()

        running_loss += loss.item()
        if i % 100 == 99:
            print(f'Epoch [{epoch+1}/{num_epochs}], Step [{i+1}/{len(trainloader)}], Loss: {running_loss/100:.4f}')
            running_loss = 0.0

print("Training finished!")

# 테스트 데이터셋을 사용하여 모델 평가
correct = 0
total = 0

with torch.no_grad():
    for data in testloader:
        images, labels = data[0].to(device), data[1].to(device)
        outputs = model(images)
        _, predicted = torch.max(outputs.data, 1)
        total += labels.size(0)
        correct += (predicted == labels).sum().item()

accuracy = 100 * correct / total
print(f'Accuracy on test set: {accuracy:.2f}%')
